Waijung 2 for Zynq 7000

SKU
waijung2_for_zynq_7000
In stock

Waijung 2 for Xilinx Zynq-7000 Key Features

  1. Generate source code and executables for Xilinx Zynq-7000 Processing System (ARM Cortex-A9 core) directly from MATLAB & Simulink.
  2. Support Xilinx native tools and toolchain (Vivado design suite, Vitis IDE and Xilinx Software Command-line Tool (XSCT)).
  3. Ability to download executables to Flash or SD card or JTAG.
  4. IEC-62304 certifiable.
  5. Operating system: Bareboard and FreeRTOS.
  6. Compatible with all simulink blocks that support Simulink embedded coder.
  7. Work with MATLAB version from 2020a or later.
  8. Applicable to all Zynq-7000 family (based on the Vivado hardware design).
  9. Support Processor-in-the-Loop (PIL) and External mode with Ethernet and Serial communication interfaces.
  10. Demos based on Digilent Zybo Z7-20 boards.

Zynq-7000 Key Features

  1. Processor (ARM Cortex-A9) and FPGA systems in one chip.
  2. Processing System (PS): ARM Cortex-A9 dual or single core.
    1. Clock:
      1. Single Core: Up to 667 MHz or 766MHz
      2. Dual Core: Up to 667MHz or 766MHz or 800MHz or 866MHz or 1GHz
    2. RAM: 256KB on-chip RAM and 16-bit or 32-bit interfaces to DDR3, DDR3L, DDR2, or LPDDR2 memories
    3. Flash:
      1. 8-bit SRAM data bus with up to 64 MB support
      2. Parallel NOR flash support
      3. ONFI 1.0 NAND flash support (1-bit ECC)
      4. 1-bit SPI, 2-bit SPI, 4-bit SPI (quad-SPI), or two quad-SPI (8-bit) serial NOR flash
  3. Programmable Logic (PL)
    1. Configurable Logic Blocks
      1. Look-up tables (LUT)
      2. Flip-flops
      3. Cascadable adders
    2. 36 Kb Block RAM
    3. Two 12-Bit Analog-to-Digital Converters

User Guide

Applications

  1. Advanced driver-assistance system (ADAS).
  2. Carrier Ethernet Backhaul.
  3. Machine Vision.
  4. Medical Endoscope.
  5. Multi-Axis Motor Control.
  6. Multi-function Printers.
  7. Professional Cameras.
  8. Programmable Logic Controller.
  9. Small Cell Baseband.

Waijung 2 for Zynq 7000 Packages

Packages (License types) [1]* Professional
(Academic)
Commercial
Within 3 day [4]* Within 1 day [4]*
Remark
[1]* Professional (Academic) and Commercial license types are annual licenses. Annual licenses provide the right to use and upgrade the software for a fixed duration of 12 months.
[2]* Require purchase of separate support package. Customization such as new feature implementations.
[3]*Only with active purchased support package.
[4]* When request using the Service request system during business day.
PackageProfessional (Academic)
Best for%s
Feature set%s
Price%s
Duration%s
Block
Technical Support Request Channel
Type of Technical Support
Time to Response%s
Remark
[1]* Professional (Academic) and Commercial license types are annual licenses. Annual licenses provide the right to use and upgrade the software for a fixed duration of 12 months.
[2]* Require purchase of separate support package. Customization such as new feature implementations.
[3]* Only with active purchased support package.
[4]* When request using the Service request system during business day.

Price Packages

Product NamePrice Package for 1-5 Licenses
(per license)
Price Package for 6-10 Licenses
(per license)
Price Package for 11-20 Licenses
(per license)
Price Package for 20+ Licenses
(per license)
Waijung 2 for Zynq-7000 Commercial56,000.00 THB50,400.00 THB44,800.00 THB39,200.00 THB
Waijung 2 for Zynq-7000 Professional (Academic)8,800.00 THB7,920.00 THB7,040.00 THB6,160.00 THB

Development Roadmap

  1. AXI Memory map block
  2. Flash block
  3. CAN bus block
  4. PWM block
  5. Firmware Upgrade block
  6. XCP block
