aMG USB Converter - N2


     FiO Glide ESP32 is an Internet of Things (IoT) module based on Espressif ESP32-WROVER-IE module, which uses ESP32-D0WD-V3 chip. It has been specifically designed to work with Waijung 2 Blockset, which is an IoT development platform, to design IoT devices with Model-Based Design technique.

FiO Glide ESP32 Key Features

  1. ESP32 Module: ESP32-WROVER-IE
    1. Flash: 16 MB
    2. PSRAM: 8 MB
    3. Antenna: IPEX
    4. WiFi: 802.11 b/g/n (802.11n up to 150 Mbps)
    5. RF frequency: 2412 ~ 2484 MHz
  2. On-board micro SD card slot
  3. On-board 512 kbits EEPROM
  4. Power supply
    1. 5V
    2. 3.3V

    Please Sign in or Create Account before download file


    1. Implement the FTDI Chip: FT2232H Dual High Speed USB to Multipurpose UART/FIFO IC
         • Single chip USB to dual serial / parallel ports with a variety of configurations.
         • Entire USB protocol handled on the chip.
         • No USB specific firmware programming required USB 2.0 High Speed (480Mbits/Second) and Full Speed (12Mbits/Seconds) compatible.
         • Dual Multi-Protocol Synchronous Serial Engine (MPSSE) to simplify synchronous serial protocol (USB to JTAG, I2C, SPI or bit-bang) design.
         • Dual independent UART or FIFO or MPSSE ports. Independent Baud rate generators
         • Fast Opto-Isolated serial interface option.
         • Free Virtual Com Port (VCP) and Direct (D2XX) drivers eliminate the requirement for USB driver development in most cases. Adjustable receive buffer timeout
         • Independent Baud rate generators
         • RS232/RS422/RS485 UART Transfer Data Rate up to 12Mbaud. (RS232 Data Rate limited by external level shifter)
         • UART Interface supports 7/8 bit data, 1/2 stop bits, and Odd/Even/Mark/Space/No Parity
         • +3.3V I/O interfacing (+5V Tolerant)
    2. Extended -40°C to 85°C industrial operating temperature range
    3. MatlabTM/Simulink block support Fast Serial Blocks enable up to 1kHz closed-loop Simulink HIL Simulation
    4. ROHS Compliant


    • Generic 2 Ports USB - Serial/SPI/I2C Converter
    • Hardware in the Loop Simulation and Test
