| Abstract | This paper proposes the method of model-based design and rapid prototyping development using the PWM Capture Block as the example. Thai block was developed by a research team of the Royal Thai Naval Academy. We use this block and others standard Simulink's blockset library to program the ultrasonic module for object detection and distance measurement functions. The Simulink code which already developed could transform to use with STM32F4, a 32-bit microcontroller, helping the developers in their prototyping development process. The results showed that the PWM Capture block could work seamlessly wiht the others standard Simulink's blockset library and compatible with 32-bit and 64-bit versions of MATLAB R2009b and beyond. The complete Simulink code could be generated to use with the embedded systems for standalone system. This can help the prototyping process to be done quickly and easily, saving time and costs. |
| Item Type | Journal Article |
| Title | Using PWM Capture Block for Model-Based Design and Rapid Prototyping Development การใช้งานบล็อกตรวจจับสัญญาณพีดับเบิลยูเอ็มเพื่อการออกแบบด้วยแบบจำลองและการพัฒนาต้นแบบอย่างเร็ว |
| Author | อุดมศักดิ์ บุญประเสริฐ |
| Publication | วารสารวิชาการ โรงเรียนนายร้อยพระจุลจอมเกล้า |
| Page | 21-28 |
| Date | 2014 |
| ISSN | 2350-9600 |
| Language | Thai |
| URL | https://ph01.tci-thaijo.org/index.php/crma-journal/article/view/243047/165281 |
| Library Catalog | ph01.tci-thaijo.org |
| Tags | Microcontroller, Model Based Design,Rapid Prototyping, Simulink, Matlab |
